AD8611ARM-REEL

IC COMPARATOR 1 W/LATCH 8MSOP

Quality Control: Learn More

Analog Devices Inc. AD8611ARM-REEL is a single-channel comparator with a latching function, packaged in an 8-MSOP. This component offers complementary, TTL-compatible outputs and operates across a supply voltage range of 3V to 5V. With a typical CMRR of 85dB and PSRR of 73dB, it provides robust performance in noisy environments. The input bias current is a maximum of 6µA at 5V, and the quiescent current is 10mA, or 4mA for the low-power version. The propagation delay is a maximum of 5.5ns, enabling fast response times. This device is suitable for applications in industrial automation and consumer electronics where precise and rapid signal comparison is required. The AD8611ARM-REEL is supplied on tape and reel.

Additional Information

Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:

Download Free CAD Model:

Technical Details:

Packaging	Tape & Reel (TR)
Package / Case	8-TSSOP, 8-MSOP (0.118"", 3.00mm Width)
Output Type	Complementary, TTL
Mounting Type	Surface Mount
Number of Elements	1
Type	with Latch
Operating Temperature	-40°C ~ 85°C
Voltage - Supply, Single/Dual (±)	3V ~ 5V
Supplier Device Package	8-MSOP
Propagation Delay (Max)	5.5ns
Current - Quiescent (Max)	10mA, 4mA
Voltage - Input Offset (Max)	7mV @ 5V
Current - Input Bias (Max)	6µA @ 5V
Current - Output (Typ)	-
CMRR, PSRR (Typ)	85dB CMRR, 73dB PSRR
Hysteresis	-
