AD8611ARM-R2
IC COMPARATOR 1 W/LATCH 8MSOPManufacturer: Analog Devices Inc.
Categories: Comparators
Quality Control: Learn More
Analog Devices Inc. AD8611ARM-R2 is a single-channel comparator featuring complementary, TTL compatible outputs and an integrated latch. This component operates with a supply voltage range of 3V to 5V, exhibiting typical CMRR and PSRR figures of 85dB and 73dB, respectively. The input bias current is specified at a maximum of 6µA at 5V, with a quiescent current of 10mA (typical) and 4mA (maximum). The propagation delay is a maximum of 5.5ns. The AD8611ARM-R2 is housed in an 8-MSOP package and is supplied on tape and reel. Its robust performance characteristics make it suitable for applications in industrial control systems, automotive electronics, and data acquisition.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Complementary, TTL |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Type | with Latch |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Single/Dual (±) | 3V ~ 5V |
| Supplier Device Package | 8-MSOP |
| Propagation Delay (Max) | 5.5ns |
| Current - Quiescent (Max) | 10mA, 4mA |
| Voltage - Input Offset (Max) | 7mV @ 5V |
| Current - Input Bias (Max) | 6µA @ 5V |
| Current - Output (Typ) | - |
| CMRR, PSRR (Typ) | 85dB CMRR, 73dB PSRR |
| Hysteresis | - |
