HMC832ALP6GETR
IC INTEGER-N/FRACTIONAL 40LFCSPManufacturer: Analog Devices Inc.
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Analog Devices Inc. HMC832ALP6GETR is an Integer-N/Fractional-N Phase-Locked Loop (PLL) synthesizer with an integrated Voltage-Controlled Oscillator (VCO). This device operates as a single-circuit frequency synthesizer, capable of generating output frequencies up to 3GHz. It features a flexible division ratio, supporting both integer and fractional division modes to achieve fine frequency resolution. The HMC832ALP6GETR includes a VCO and offers a ratio of Input:Output of 1:2. It is housed in a 40-LFCSP (6x6) package with an exposed pad, designed for surface mounting. Power is supplied via a voltage range of 3.1V to 3.5V, and it operates within an ambient temperature range of -40°C to 85°C. This component is commonly utilized in applications requiring precise frequency generation and synthesis, such as wireless infrastructure, test and measurement equipment, and radar systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 40-VFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 3GHz |
| Type | Integer-N/Fractional-N, VCO |
| Input | Clock |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.1V ~ 3.5V |
| Ratio - Input:Output | 1:2 |
| Differential - Input:Output | No/Yes |
| Supplier Device Package | 40-LFCSP (6x6) |
| PLL | Yes |
| Divider/Multiplier | Yes/No |
| Number of Circuits | 1 |
| Programmable | Not Verified |
