HMC765LP6CE
IC PLL W/VCO FRACT-N 40-QFNManufacturer: Analog Devices Inc.
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Analog Devices Inc. HMC756LP6CE is a fractional-N Phase-Locked Loop (PLL) Synthesizer with integrated Voltage-Controlled Oscillator (VCO). This monolithic IC operates up to 8.8 GHz, delivering precise frequency synthesis for demanding applications. It features a single circuit with a 1:1 input-to-output ratio and supports both differential and single-ended inputs and outputs. The device is housed in a 40-VFQFN exposed pad package, suitable for high-density surface mounting. Operating across a wide industrial temperature range of -40°C to 85°C, the HMC756LP6CE is powered by a supply voltage from 1.8V to 5.5V. This component is commonly utilized in wireless infrastructure, radar systems, and test and measurement equipment.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Strip |
| Package / Case | 40-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 8.8GHz |
| Input | Clock |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.8V ~ 5.5V |
| Ratio - Input:Output | 1:1 |
| Differential - Input:Output | Yes/No |
| Supplier Device Package | 40-SMT (6x6) |
| PLL | Yes |
| Divider/Multiplier | Yes/No |
| Number of Circuits | 1 |
| Programmable | Not Verified |
