ADF4212BRU
IC PLL FREQ SYNTHESIZER 20-TSSOPManufacturer: Analog Devices Inc.
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Analog Devices Inc. ADF4212BRU is a high-performance Clock/Frequency Synthesizer (RF/IF) IC. This versatile component operates up to 2.7GHz and features a Phase-Locked Loop (PLL) architecture. It is housed in a compact 20-TSSOP (0.173", 4.40mm Width) surface mount package. The ADF4212BRU supports a supply voltage range of 2.7V to 5.5V, making it suitable for a wide array of applications. Its capabilities include an input that accepts CMOS signals and an output designed for clock distribution. This device is commonly utilized in RF communications, test and measurement equipment, and radar systems. The component offers a 3:1 input-to-output ratio.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 2.7GHz |
| Type | Clock/Frequency Synthesizer (RF/IF) |
| Input | CMOS |
| Voltage - Supply | 2.7V ~ 5.5V |
| Ratio - Input:Output | 3:1 |
| Differential - Input:Output | Yes/No |
| Supplier Device Package | 20-TSSOP |
| PLL | Yes |
| Divider/Multiplier | No/No |
| Programmable | Not Verified |
