ADF4159WCCPZ-RL7
IC FREQ SYNTH 24LFCSPManufacturer: Analog Devices Inc.
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Analog Devices Inc. ADF4159WCCPZ-RL7 is a high-performance frequency synthesizer, operating up to 13GHz. This single-circuit synthesizer features a PLL architecture with a 2:1 ratio capability for input-to-output division or multiplication. It accepts CMOS and TTL inputs and provides a CMOS output. Designed for demanding applications, the ADF4159WCCPZ-RL7 supports differential input and output signals, enhancing signal integrity. The device is housed in a 24-WFQFN exposed pad, CSP (24-LFCSP-WQ 4x4) package and is suitable for surface mount assembly. Operating within an automotive grade temperature range of -40°C to 125°C, it requires a supply voltage between 1.62V and 3.45V. This component finds extensive use in RF systems, wireless communication infrastructure, and test and measurement equipment. It is supplied in a tape and reel package.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-WFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Output | CMOS |
| Frequency - Max | 13GHz |
| Type | Frequency Synthesizer |
| Input | CMOS, TTL |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Voltage - Supply | 1.62V ~ 3.45V |
| Ratio - Input:Output | 2:1 |
| Differential - Input:Output | Yes/No |
| Supplier Device Package | 24-LFCSP-WQ (4x4) |
| PLL | Yes |
| Divider/Multiplier | Yes/No |
| Grade | Automotive |
| Number of Circuits | 1 |
| Programmable | Not Verified |
