ADF4153YCPZ-RL
IC SYNTH FRACT-N FREQ 20-LFCSPManufacturer: Analog Devices Inc.
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Analog Devices Inc. ADF4153YCPZ-RL is a Fractional N Synthesizer (RF) IC operating up to 4GHz. This device features a PLL architecture with a single circuit and supports differential input/output. The input accepts CMOS and TTL logic levels, while the output provides a clock signal. The ADF4153YCPZ-RL is housed in a 20-LFCSP-VQ (4x3.75) package, suitable for surface mount applications. It operates within a voltage range of 2.7V to 3.3V and is rated for an operating temperature of -40°C to 125°C. This component is utilized in applications requiring precise frequency generation and control, including wireless infrastructure, test and measurement equipment, and radar systems. The device facilitates a 2:1 ratio between input and output frequencies.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 20-VFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 4GHz |
| Type | Fractional N Synthesizer (RF) |
| Input | CMOS, TTL |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 2.7V ~ 3.3V |
| Ratio - Input:Output | 2:1 |
| Differential - Input:Output | Yes/No |
| Supplier Device Package | 20-LFCSP-VQ (4x3.75) |
| PLL | Yes |
| Divider/Multiplier | No/Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
