SSM2212RZ
TRANS 2NPN 40V 0.02A 8SOICManufacturer: Analog Devices Inc.
Categories: Bipolar Transistor Arrays
Quality Control: Learn More
Bipolar (BJT) Transistor Array 2 NPN (Dual) Matched Pair 40V 20mA 200MHz Surface Mount 8-SOIC
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Transistor Type | 2 NPN (Dual) Matched Pair |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Power - Max | - |
| Current - Collector (Ic) (Max) | 20mA |
| Voltage - Collector Emitter Breakdown (Max) | 40V |
| Vce Saturation (Max) @ Ib, Ic | 200mV @ 100µA, 1mA |
| Current - Collector Cutoff (Max) | 500pA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | - |
| Frequency - Transition | 200MHz |
| Supplier Device Package | 8-SOIC |
