SSM2317-001CBZ-RL
IC AMP CLASS D MONO 3.89W WLCSPManufacturer: Analog Devices Inc.
Categories: Audio Amplifiers
Quality Control: Learn More
Analog Devices Inc. SSM2317-001CBZ-RL is a 1-channel Class D audio amplifier IC designed for high-efficiency operation. This mono amplifier delivers 3.89W into a 3 Ohm load, making it suitable for demanding audio applications. Key features include integrated depop circuitry, differential inputs for improved noise immunity, and robust protection against short-circuit and thermal events. A shutdown pin facilitates power management. The SSM2317-001CBZ-RL operates from a 2.5V to 5.5V supply range and is supplied in a WLCSP package, suitable for surface mount applications. This component finds application in portable electronics, consumer audio devices, and other systems requiring compact, high-fidelity audio amplification.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Depop, Differential Inputs, Short-Circuit and Thermal Protection, Shutdown |
| Packaging | Tape & Reel (TR) |
| Package / Case | - |
| Output Type | 1-Channel (Mono) |
| Mounting Type | Surface Mount |
| Type | Class D |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.5V ~ 5.5V |
| Max Output Power x Channels @ Load | 3.89W x 1 @ 3Ohm |
| Supplier Device Package | - |
