SSM2301CPZ-REEL7
IC AMP AUDIO 1.52W MONO D 8LFCSPManufacturer: Analog Devices Inc.
Categories: Audio Amplifiers
Quality Control: Learn More
Analog Devices Inc. SSM2301CPZ-REEL7 is a mono Class D audio amplifier IC. This 1-channel device is housed in an 8-LFCSP-VD (3x3) package, featuring exposed pad for enhanced thermal performance. It delivers 1.52W into an 8 Ohm load. Key features include integrated depop circuitry, differential inputs, and comprehensive protection against short-circuit and thermal events, along with a shutdown pin for power management. The SSM2301CPZ-REEL7 operates from a 2.5V to 5V supply and is suitable for applications requiring efficient audio amplification, such as portable electronics and consumer audio systems. Its surface mount design and robust protection features make it a reliable choice for demanding environments.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Depop, Differential Inputs, Short-Circuit and Thermal Protection, Shutdown |
| Packaging | Cut Tape (CT) |
| Package / Case | 8-VFDFN Exposed Pad, CSP |
| Output Type | 1-Channel (Mono) |
| Mounting Type | Surface Mount |
| Type | Class D |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.5V ~ 5V |
| Max Output Power x Channels @ Load | 1.52W x 1 @ 8Ohm |
| Supplier Device Package | 8-LFCSP-VD (3x3) |
