ADN2905ACPZ-RL7
IC CLK/DATA REC 10.3GBPS 24LFCSPManufacturer: Analog Devices Inc.
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Analog Devices Inc. ADN2905ACPZ-RL7 is a clock and data recovery IC designed for high-speed serial data transmission. This component operates at up to 10.3Gbps, facilitating robust signal integrity in demanding networking applications. It features a 1:1 input-to-output ratio with both CML inputs and outputs, ensuring compatibility with various high-speed interfaces. The ADN2905ACPZ-RL7 includes an integrated PLL for precise clock recovery. Packaged in a 24-LFCSP (4x4) for surface mounting, this device is suitable for operation across a wide temperature range of -40°C to 85°C, with a supply voltage range of 1.14V to 3.63V. Its capabilities make it a valuable component for Ethernet infrastructure, data communications, and other high-performance timing-critical systems. The device is supplied on tape and reel.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-WFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Output | CML |
| Frequency - Max | 10.3Gbps |
| Input | CML |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.14V ~ 3.63V |
| Main Purpose | Ethernet |
| Ratio - Input:Output | 1:1 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 24-LFCSP (4x4) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
