AD800-52BR
IC CLKDATA RECOVERY PLL 20-SOICManufacturer: Analog Devices Inc.
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Analog Devices Inc. AD800-52BR is an Electronic Component designed for high-speed clock and data recovery applications. This device functions as a DS-3, STS-1 Clock and Data Recovery (CDR) and Fanout Buffer, operating at a maximum frequency of 51.84MHz. It features an ECL differential input and ECL output, with a 1:2 input-to-output ratio. The AD800-52BR includes a Phase-Locked Loop (PLL) for precise clock generation and synchronization. Housed in a 20-SOIC package, this surface-mount component is suitable for operation across a temperature range of -40°C to 85°C. Its specifications make it ideal for telecommunications infrastructure, including digital transmission systems and high-speed data networking. The device is supplied in a tube.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Output | ECL |
| Frequency - Max | 51.84MHz |
| Input | ECL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | -4.5V ~ -5.5V |
| Main Purpose | DS-3, STS-1 |
| Ratio - Input:Output | 1:2 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 20-SOIC |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
