ADA4571WHRZ-R7
SENSOR ANGLE 180DEG SMDManufacturer: Analog Devices Inc.
Categories: Angle, Linear Position Measuring
Quality Control: Learn More
Analog Devices Inc. ADA4571WHRZ-R7 is a magnetoresistive sensor designed for angle measurement. This automotive-grade component provides sine and cosine analog voltage outputs, enabling precise 180-degree angle detection. It requires an external magnet actuator, which is not included. The device features a surface mountable 8-SOIC package with gull wing termination, suitable for high-volume manufacturing. Operating across a wide temperature range of -40°C to 125°C, the ADA4571WHRZ-R7 supports supply voltages from 2.7V to 5.5V. Its technology is based on magnetoresistive principles, offering reliable performance in demanding applications. This component is commonly utilized in automotive systems such as steering angle sensing, electronic stability control, and motor control.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Output | Analog Voltage |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | Gull Wing |
| Voltage - Supply | 2.7V ~ 5.5V |
| Linearity | - |
| Linear Range | - |
| Actuator Type | External Magnet, Not Included |
| Technology | Magnetoresistive |
| Resistance Tolerance | - |
| For Measuring | Angle |
| Supplier Device Package | 8-SOIC |
| Rotation Angle - Electrical, Mechanical | 180° (±90°), Continuous |
| Output Signal | Cosine, Sine |
| Grade | Automotive |
| Programmable | - |
