LTC2323IUFD-16#TRPBF
IC ADC 16BIT SAR 28QFNManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
The Analog Devices Inc. LTC2323IUFD-16-TRPBF is a dual-channel, 16-bit successive approximation register (SAR) analog-to-digital converter (ADC). This component features simultaneous sampling capabilities, supporting two differential or pseudo-differential inputs. The device operates with an analog supply voltage range of 3.13V to 5V and a digital supply of 1.71V to 2.63V. It boasts a high sampling rate of 5Msps per channel and offers both internal and external reference options. The LTC2323IUFD-16-TRPBF utilizes an LVDS serial data interface for efficient data transfer. Housed in a 28-QFN (4x5) package suitable for surface mounting, this ADC is designed for applications requiring high-speed, accurate signal acquisition across industries such as medical imaging, test and measurement, and communications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Simultaneous Sampling |
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Number of Bits | 16 |
| Configuration | S/H-ADC |
| Data Interface | LVDS - Serial, Serial |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 3.13V ~ 3.47V, 5V |
| Voltage - Supply, Digital | 1.71V ~ 2.63V |
| Sampling Rate (Per Second) | 5M |
| Input Type | Differential, Pseudo-Differential |
| Number of Inputs | 2 |
| Supplier Device Package | 28-QFN (4x5) |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 2 |
