LTC1403AIMSE#TRPBF
IC ADC 14BIT SAR 10MSOPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
The Analog Devices Inc. LTC1403AIMSE-TRPBF is a 14-bit successive approximation (SAR) Analog to Digital Converter (ADC) with a sampling rate of 2.8 MSPS. This component features a single input channel and supports both differential and single-ended input types. The device offers a flexible reference option, allowing for either external or internal voltage references. Its data interface is SPI, and it operates within an analog and digital supply voltage range of 2.7V to 3.6V. The LTC1403AIMSE-TRPBF is housed in a 10-MSOP-EP (Exposed Pad) package, suitable for surface mount applications. Operating temperature ranges from -40°C to 85°C. This ADC is commonly utilized in applications requiring high-speed data acquisition, including industrial control systems, medical instrumentation, and portable test equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-TFSOP, 10-MSOP (0.118"", 3.00mm Width) Exposed Pad |
| Mounting Type | Surface Mount |
| Number of Bits | 14 |
| Configuration | S/H-ADC |
| Data Interface | SPI |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 2.7V ~ 3.6V |
| Voltage - Supply, Digital | 2.7V ~ 3.6V |
| Sampling Rate (Per Second) | 2.8M |
| Input Type | Differential, Single Ended |
| Number of Inputs | 1 |
| Supplier Device Package | 10-MSOP-EP |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
