LTC1276BCN#PBF
IC ADC 12BIT SAR 24DIPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
The Analog Devices Inc. LTC1276BCN-PBF is a 12-bit successive approximation register (SAR) analog-to-digital converter (ADC). This component features a single input and a sample-and-hold (S/H) amplifier integrated with the SAR architecture. It offers a sampling rate of up to 300 kSPS and provides a parallel data interface for output. The device supports analog supply voltages of ±5V and 5V, with a 5V digital supply. Designed for through-hole mounting, it comes in a 24-PDIP package. The LTC1276BCN-PBF is suitable for applications in industrial control, data acquisition systems, and instrumentation. It operates within a temperature range of 0°C to 70°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 24-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Number of Bits | 12 |
| Configuration | S/H-ADC |
| Data Interface | Parallel |
| Reference Type | Internal |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply, Analog | ±5V, 5V |
| Voltage - Supply, Digital | 5V |
| Sampling Rate (Per Second) | 300k |
| Input Type | Single Ended |
| Number of Inputs | 1 |
| Supplier Device Package | 24-PDIP |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
