ADADC71KD
IC ADC 16BIT SAR 32BBDIPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Analog Devices Inc. ADADC71KD is a 16-bit Analog-to-Digital Converter (ADC) featuring a Successive Approximation Register (SAR) architecture. This through-hole component utilizes a parallel data interface and is housed in a 32-BBDIP-H package. It offers a single-ended input and an internal reference, with a sampling rate of 20kSPS. The device operates with analog supply voltages of ±15V and digital supply voltages of ±5V. The ADADC71KD is suitable for applications in industrial instrumentation and data acquisition systems requiring precise analog-to-digital conversion.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 32-CDIP (0.910"", 23.12mm) |
| Mounting Type | Through Hole |
| Number of Bits | 16 |
| Configuration | ADC |
| Data Interface | Parallel |
| Reference Type | Internal |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply, Analog | ±15V |
| Voltage - Supply, Digital | ±5V |
| Sampling Rate (Per Second) | 20k |
| Input Type | Single Ended |
| Number of Inputs | 1 |
| Supplier Device Package | 32-BBDIP-H |
| Architecture | SAR |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
