AD9629BCPZRL7-80
IC ADC 12BIT PIPELINED 32LFCSPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Analog Devices Inc. AD9629BCPZRL7-80 is a 12-bit pipelined Analog-to-Digital Converter (ADC) designed for high-speed data acquisition. This single-channel device operates at a sampling rate of up to 80 MSPS, featuring a pipelined architecture that balances resolution and throughput. The AD9629BCPZRL7-80 supports both single-ended and differential input types, with a 1:1 S/H-to-ADC ratio. It offers flexible reference options, accommodating both external and internal references. The device is supplied in a 32-LFCSP-VQ (5x5) surface-mount package, presented on a Tape & Reel (TR). Typical applications include digital signal processing, test and measurement equipment, and medical imaging systems. Analog supply voltage ranges from 1.7V to 1.9V, with digital supply voltage ranging from 1.7V to 3.6V. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Configuration | S/H-ADC |
| Data Interface | Parallel |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 1.7V ~ 1.9V |
| Voltage - Supply, Digital | 1.7V ~ 3.6V |
| Sampling Rate (Per Second) | 80M |
| Input Type | Differential, Single Ended |
| Number of Inputs | 1 |
| Supplier Device Package | 32-LFCSP-VQ (5x5) |
| Architecture | Pipelined |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
