AD9271BSVZ-25
IC ADC OCT 12BIT 25MSPS 100-TQFPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Analog Devices Inc. AD9271BSVZ-25 is a 12-bit, 8-channel octal analog-to-digital converter (ADC) operating at a sampling rate of 25 MSPS. This pipelined ADC features a LNA-VGA-AAF-ADC architecture, suitable for applications requiring simultaneous sampling. The data interface is LVDS serial, and it supports both differential and single-ended input types. The component is housed in a 100-TQFP-EP (14x14) surface-mount package. It offers both internal and external reference types and operates efficiently with analog and digital supply voltages of 1.8V. This device finds application in areas such as medical imaging, communications infrastructure, and test and measurement equipment.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Simultaneous Sampling |
| Packaging | Tray |
| Package / Case | 100-TQFP Exposed Pad |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Configuration | LNA-VGA-AAF-ADC |
| Data Interface | LVDS - Serial |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 1.8V |
| Voltage - Supply, Digital | 1.8V |
| Sampling Rate (Per Second) | 25M |
| Input Type | Differential, Single Ended |
| Number of Inputs | 8 |
| Supplier Device Package | 100-TQFP-EP (14x14) |
| Architecture | Pipelined |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
