AD7634BSTZRL
IC ADC 18BIT SAR 48LQFPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Analog Devices Inc. AD7634BSTZRL is an 18-bit successive approximation analog-to-digital converter (ADC) from the iCMOS® and PulSAR® series. This SAR ADC features a single input and a 1:1 S/H to ADC ratio, offering a sampling rate of up to 670 kSPS. Designed for surface mounting, it is housed in a 48-LQFP (7x7) package and supplied on tape and reel. The device supports SPI, Parallel, and DSP data interfaces, with analog and digital supply voltage requirements of 5V. It accommodates both external and internal reference types. This component is suitable for applications in industrial automation, medical instrumentation, and high-precision data acquisition systems.
Additional Information
Series: iCMOS®, PulSAR®RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-LQFP |
| Mounting Type | Surface Mount |
| Number of Bits | 18 |
| Configuration | S/H-ADC |
| Data Interface | SPI, Parallel, DSP |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Sampling Rate (Per Second) | 670k |
| Input Type | Differential |
| Number of Inputs | 1 |
| Supplier Device Package | 48-LQFP (7x7) |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
