AD7292BCPZ-RL
IC ADC 10BIT SAR 36LFCSPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Analog Devices AD7292BCPZ-RL is a 10-bit successive approximation analog-to-digital converter (ADC). This component features a single 1-channel, 8-input multiplexer (MUX) and a sample-and-hold (S/H) circuit. The AD7292BCPZ-RL operates with an analog supply voltage of 5V and a digital supply voltage ranging from 1.8V to 5.25V. It offers a sampling rate of 625kSPS and supports both external and internal voltage references. The data interface is SPI compatible. Additional features include an integrated temperature sensor. Input types are configurable as differential or single-ended. The device is supplied in a 36-lead LFCSP-WQ (6x6mm) surface-mount package on tape and reel. This component is commonly utilized in industrial automation, medical instrumentation, and consumer electronics applications.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Sensor |
| Packaging | Tape & Reel (TR) |
| Package / Case | 36-WFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Number of Bits | 10 |
| Configuration | MUX-S/H-ADC |
| Data Interface | SPI |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 1.8V ~ 5.25V |
| Sampling Rate (Per Second) | 625k |
| Input Type | Differential, Single Ended |
| Number of Inputs | 1, 8 |
| Supplier Device Package | 36-LFCSP-WQ (6x6) |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
