AD1380KD
IC ADC 16BIT SAR 32BBDIPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Analog Devices Inc. AD1380KD is a 16-bit successive approximation analog-to-digital converter (ADC) featuring a 50 kSPS sampling rate. This component offers 16 single-ended analog inputs and a 1:1 sample-and-hold to ADC ratio. The AD1380KD utilizes an internal reference and provides a parallel data interface. It operates with analog supply voltages of ±14.5V to ±15.5V and a digital supply of 5V. Packaged in a 32-lead ceramic dual in-line package (CDIP), this device is suitable for through-hole mounting. The operating temperature range is 0°C to 70°C. This particular model is supplied in tube packaging. Applications for this component can be found in industrial automation and data acquisition systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 32-CDIP (0.910"", 23.12mm) |
| Mounting Type | Through Hole |
| Number of Bits | 16 |
| Configuration | S/H-ADC |
| Data Interface | Parallel |
| Reference Type | Internal |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply, Analog | ±14.5V ~ 15.5V |
| Voltage - Supply, Digital | 5V |
| Sampling Rate (Per Second) | 50k |
| Input Type | Single Ended |
| Number of Inputs | 16 |
| Supplier Device Package | 32-BBDIP-H |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
