AD1380JD
IC ADC 16BIT SAR 32BBDIPManufacturer: Analog Devices Inc.
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Analog Devices Inc. AD1380JD is a 16-bit successive approximation analog-to-digital converter (ADC) designed for high-precision data acquisition. This component features a 16-input multiplexer and a single SAR ADC core, offering a 1:1 ratio for sample-and-hold to ADC conversion. The AD1380JD utilizes a parallel data interface for efficient data transfer. It operates with analog supply voltages of ±14.5V to ±15.5V and digital supply voltages of 5V. The device is packaged in a 32-pin ceramic dual in-line package (32-CDIP) suitable for through-hole mounting. With an internal reference and a sampling rate of up to 50kSPS, this ADC is well-suited for applications in industrial control, instrumentation, and data acquisition systems requiring accurate analog signal conversion. The operating temperature range is 0°C to 70°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 32-CDIP (0.910"", 23.12mm) |
| Mounting Type | Through Hole |
| Number of Bits | 16 |
| Configuration | S/H-ADC |
| Data Interface | Parallel |
| Reference Type | Internal |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply, Analog | ±14.5V ~ 15.5V |
| Voltage - Supply, Digital | 5V |
| Sampling Rate (Per Second) | 50k |
| Input Type | Single Ended |
| Number of Inputs | 16 |
| Supplier Device Package | 32-BBDIP-H |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
