ADG5401FBCPZ-RL7
IC SWITCH SPST-NCX1 6OHM 10LFCSPManufacturer: Analog Devices Inc.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
1 Circuit IC Switch 1:1 6Ohm (Typ) 10-LFCSP (3x2)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-WFDFN, CSP |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| On-State Resistance (Max) | 6Ohm (Typ) |
| -3db Bandwidth | 395MHz |
| Supplier Device Package | 10-LFCSP (3x2) |
| Voltage - Supply, Single (V+) | 8V ~ 44V |
| Voltage - Supply, Dual (V±) | ±5V ~ 22V |
| Charge Injection | -230pC |
| Crosstalk | - |
| Switch Circuit | SPST - NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | - |
| Switch Time (Ton, Toff) (Max) | 10.2µs, 360ns |
| Channel Capacitance (CS(off), CD(off)) | 9pF, 11pF |
| Current - Leakage (IS(off)) (Max) | 100pA (Typ) |
| Number of Circuits | 1 |
