ADG1419BRMZ-REEL7
IC SWITCH SPDT X 1 2.4OHM 8MSOPManufacturer: Analog Devices Inc.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
1 Circuit IC Switch 2:1 2.4Ohm 8-MSOP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| On-State Resistance (Max) | 2.4Ohm |
| -3db Bandwidth | 135MHz |
| Supplier Device Package | 8-MSOP |
| Voltage - Supply, Single (V+) | 5V ~ 16.5V |
| Voltage - Supply, Dual (V±) | ±4.5V ~ 16.5V |
| Charge Injection | -16pC |
| Crosstalk | -64dB @ 1MHz |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 50mOhm |
| Switch Time (Ton, Toff) (Max) | 110ns, 140ns |
| Channel Capacitance (CS(off), CD(off)) | 19pF, 44pF |
| Current - Leakage (IS(off)) (Max) | 500pA |
| Number of Circuits | 1 |
