ADG1206YRUZ-REEL7
IC MUX 16:1 200OHM 28TSSOPManufacturer: Analog Devices Inc.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
1 Circuit IC Switch 16:1 200Ohm 28-TSSOP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| On-State Resistance (Max) | 200Ohm |
| -3db Bandwidth | 280MHz |
| Supplier Device Package | 28-TSSOP |
| Voltage - Supply, Single (V+) | 5V ~ 16.5V |
| Voltage - Supply, Dual (V±) | ±5V ~ 16.5V |
| Charge Injection | 0.5pC |
| Crosstalk | -85dB @ 1MHz |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 16:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 3.5Ohm |
| Switch Time (Ton, Toff) (Max) | 95ns, 100ns |
| Channel Capacitance (CS(off), CD(off)) | 2pF, 12pF |
| Current - Leakage (IS(off)) (Max) | 200pA |
| Number of Circuits | 1 |
Request a Quote
