AD7816ARMZ-REEL7
IC ADC 10BIT W/TEMP SNSR 8MSOPManufacturer: Analog Devices Inc.
Categories: Analog and Digital Output
Quality Control: Learn More
Analog Devices AD7816ARMZ-REEL7 is a 10-bit analog-to-digital converter (ADC) with integrated local temperature sensing capabilities. This component features a digital output interface compatible with SPI communication protocols, enabling efficient data transfer in embedded systems. The device operates within a supply voltage range of 2.7V to 5.5V and is housed in an 8-MSOP package, suitable for surface mount applications. The local temperature sensor offers a sensing range from -40°C to 85°C with an accuracy of ±2°C at 25°C and ±3°C across its operating range. This ADC is designed for applications requiring precise temperature monitoring and data acquisition, commonly found in consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | SPI |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply | 2.7V ~ 5.5V |
| Sensor Type | Digital, Local |
| Resolution | 10 b |
| Supplier Device Package | 8-MSOP |
| Test Condition | 25°C (-40°C ~ 85°C) |
| Accuracy - Highest (Lowest) | ±2°C (±3°C) |
| Sensing Temperature - Local | -40°C ~ 85°C |
| Sensing Temperature - Remote | - |
Request a Quote
