AD7720BRU-REEL
IC MODULATOR SIGMA-DELTA 28TSSOPManufacturer: Analog Devices Inc.
Categories: ADCs/DACs - Special Purpose
Quality Control: Learn More
Analog Devices Inc. AD7720BRU-REEL is a 16-bit Sigma-Delta Modulator designed for high-precision data acquisition. This component features a parallel data interface, enabling a sampling rate of up to 12.5 MSPS. Packaged in a 28-TSSOP (0.173", 4.40mm width) surface-mount configuration, it operates from a 5V supply with balanced analog and digital voltage sources. The AD7720BRU-REEL is suitable for applications requiring accurate analog-to-digital conversion, including industrial automation, medical instrumentation, and high-fidelity audio processing. Its robust design and efficient modulation technique make it a valuable component for demanding signal processing tasks.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Type | Sigma-Delta Modulator |
| Data Interface | Parallel |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 5V |
| Sampling Rate (Per Second) | 12.5M |
| Resolution (Bits) | 16 b |
| Voltage Supply Source | Analog and Digital |
| Supplier Device Package | 28-TSSOP |
| Number of Channels | 1 |
