MAX6079ALA25+
IC VREF SERIES 0.04% 8LCCManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Voltage Reference
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX6079ALA25- is a high-precision series voltage reference IC offering a fixed 2.5V output with an exceptional ±0.04% tolerance. Designed for demanding applications, this component features a low temperature coefficient of 6ppm/°C and low noise performance, with 4.8µVp-p from 0.1Hz to 10Hz and 6µVrms from 10Hz to 10kHz. It operates with an input voltage range of 2.8V to 5.5V and provides an output current of up to 10 mA, while consuming only 330µA of supply current. The MAX6079ALA25- is suitable for surface mount applications and comes in an 8-LCC (3x3) package. This device is utilized in industries such as industrial automation, test and measurement, and medical equipment where precise voltage regulation is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 23 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±0.04% |
| Packaging | Tray |
| Package / Case | 8-CLCC |
| Temperature Coefficient | 6ppm/°C |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Voltage - Input | 2.8V ~ 5.5V |
| Reference Type | Series |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Current - Supply | 330µA |
| Supplier Device Package | 8-LCC (3x3) |
| Voltage - Output (Min/Fixed) | 2.5V |
| Noise - 0.1Hz to 10Hz | 4.8µVp-p |
| Noise - 10Hz to 10kHz | 6µVrms |
| Current - Output | 10 mA |
