MAX6012BEUR-T
IC VREF SERIES 0.48% SOT23-3Manufacturer: Analog Devices Inc./Maxim Integrated
Categories: Voltage Reference
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX6012BEUR-T is a fixed voltage reference IC offering a stable 1.247V output with a ±0.48% tolerance. This series voltage reference operates with a supply current of 35µA and can source up to 500 µA of output current. Key performance specifications include a temperature coefficient of 30ppm/°C and low noise characteristics, with 12µVp-p from 0.1Hz to 10Hz and 65µVrms from 10Hz to 10kHz. Designed for surface mounting, it utilizes the SOT-23-3 package. The input voltage range is 2.5V to 12.6V, and it operates within an ambient temperature range of -40°C to 85°C. This component is widely employed in industrial, medical, and automotive applications requiring precise voltage regulation. The MAX6012BEUR-T is supplied on tape and reel.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±0.48% |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Temperature Coefficient | 30ppm/°C |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Voltage - Input | 2.5V ~ 12.6V |
| Reference Type | Series |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Current - Supply | 35µA |
| Supplier Device Package | SOT-23-3 |
| Voltage - Output (Min/Fixed) | 1.247V |
| Noise - 0.1Hz to 10Hz | 12µVp-p |
| Noise - 10Hz to 10kHz | 65µVrms |
| Current - Output | 500 µA |
