DS9502P+T&R
TVS DIODE 7.5VWM 6TSOCManufacturer: Analog Devices Inc./Maxim Integrated
Categories: TVS Diodes
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated TVS Diode, part number DS9502P-T-R, is a surface-mount transient voltage suppressor designed for robust protection. This component features a reverse standoff voltage of 7.5V and a typical breakdown voltage of 9V. The 6-TSOC package is suitable for compact designs in applications requiring protection against voltage transients. Its operating temperature range is -40°C to 85°C. This device is utilized in general-purpose applications where reliable overvoltage protection is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-SMD, J-Lead |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | - |
| Voltage - Reverse Standoff (Typ) | 7.5V |
| Supplier Device Package | 6-TSOC |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 9V (Typ) |
| Voltage - Clamping (Max) @ Ipp | - |
| Power - Peak Pulse | - |
| Power Line Protection | No |
