MAX6315US48D2-T
IC SUPERVISOR 1 CHANNEL SOT143-4Manufacturer: Analog Devices Inc./Maxim Integrated
Categories: Supervisors
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX6315US48D2-T is a single-channel supervisory circuit designed for robust system reliability. This SOT-143-4 packaged component monitors a single voltage threshold set at 4.8V. Featuring an open-drain or open-collector output, it provides an active-low reset signal with a minimum timeout of 20ms. The device operates across a wide temperature range of -40°C to 125°C (TA), making it suitable for demanding applications. Its surface mount capability, delivered in a tape and reel package, facilitates efficient automated assembly. This component finds application in various industries, including automotive, industrial control, and consumer electronics, where precise voltage monitoring and reliable reset functionality are critical.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-253-4, TO-253AA |
| Mounting Type | Surface Mount |
| Output | Open Drain or Open Collector |
| Type | Simple Reset/Power-On Reset |
| Reset | Active Low |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Number of Voltages Monitored | 1 |
| Reset Timeout | 20ms Minimum |
| Voltage - Threshold | 4.8V |
| Supplier Device Package | SOT-143-4 |
| Programmable | Not Verified |
