MAX1711EEG
IC REG PWM CTRLR 1OUT 24QSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Special Purpose Regulators
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX1711EEG is a Quick-PWM™ PWM controller designed for CPU core voltage regulation. This single-output device, packaged in a 24-QSOP, operates within an input voltage range of 4.5V to 5.5V, providing adjustable output voltages from 0.925V to 2V. Its surface-mount design and 24-SSOP package facilitate efficient integration into compact board layouts. Operating across a temperature range of -40°C to 85°C, the MAX1711EEG is suited for applications requiring precise and dynamic voltage control, including high-performance computing and advanced power management systems.
Additional Information
Series: Quick-PWM™RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-SSOP (0.154"", 3.90mm Width) |
| Voltage - Output | 0.925V ~ 2V |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Voltage - Input | 4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Applications | PWM Controller, CPU core |
| Supplier Device Package | 24-QSOP |
