MAX4938CTN+T
IC TRANSMIT/RCVR SWITCH 56-TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Special Purpose
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX4938CTN-T is an 8-channel ultrasound switch IC designed for high-performance signal routing. This component offers a -3dB bandwidth of 65MHz, making it suitable for demanding ultrasound applications. It operates from single or dual supply voltages, with a single supply range of 1.62V to 5.5V and a dual supply range of ±2.7V to ±5.5V. The device is presented in a 56-TQFN (11x5) exposed pad package, facilitating surface mounting. This IC is commonly utilized in medical imaging and diagnostic equipment. The MAX4938CTN-T is supplied in a Tape & Reel (TR) package.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 56-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Applications | Ultrasound |
| On-State Resistance (Max) | - |
| -3db Bandwidth | 65MHz |
| Supplier Device Package | 56-TQFN (11x5) |
| Voltage - Supply, Single (V+) | 1.62V ~ 5.5V |
| Voltage - Supply, Dual (V±) | ±2.7V ~ 5.5V |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | - |
| Number of Channels | 8 |
