MAX4888BGTI+
IC SWITCH DUAL DPDT 28TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Special Purpose
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX4888BGTI- is a dual DPDT (Double Pole Double Throw) analog switch designed for high-speed data transmission. This PCI Express® switch IC features two independent channels, each capable of supporting DPDT switching. With a -3dB bandwidth of 8GHz, it is well-suited for applications requiring robust signal integrity at high frequencies. The device operates from a single 3V to 3.6V supply and has an on-state resistance of 8.4 Ohms maximum.
Packaged in a 28-TQFN (3.5x5.5) with an exposed pad for enhanced thermal performance, the MAX4888BGTI- is designed for surface mount applications. Its operating temperature range of -40°C to 85°C makes it suitable for demanding environments found in computing, networking, and telecommunications infrastructure.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 28-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | PCI Express® |
| On-State Resistance (Max) | 8.4Ohm |
| -3db Bandwidth | 8GHz |
| Supplier Device Package | 28-TQFN (3.5x5.5) |
| Voltage - Supply, Single (V+) | 3V ~ 3.6V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | DPDT |
| Multiplexer/Demultiplexer Circuit | - |
| Number of Channels | 2 |
