MAX4885EETG+CK2
IC MULTIPLEXER 2X1 24-TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Special Purpose
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX4885EETG-CK2 is a high-performance video switch IC designed for 1-channel applications. This SPDT (Single Pole Double Throw) switch features a 2x1 multiplexer configuration, enabling efficient signal routing. With a typical on-state resistance of 6 Ohms, it minimizes signal degradation. The device operates from a single supply voltage ranging from 2V to 5.5V and is specified for an operating temperature range of -40°C to 85°C (TA). The MAX4885EETG-CK2 is housed in a compact 24-TQFN (4x4) package with an exposed pad, suitable for surface mounting. Its capabilities are leveraged in video applications, including those requiring RGB signal handling.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | RGB |
| Packaging | Tray |
| Package / Case | 24-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Video |
| On-State Resistance (Max) | 6Ohm (Typ) |
| -3db Bandwidth | - |
| Supplier Device Package | 24-TQFN (4x4) |
| Voltage - Supply, Single (V+) | 2V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Channels | 1 |
