MAX4951BECTP+GH7
IC REDRIVER ESATA 1CH 20TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Signal Buffers, Repeaters, Splitters
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX4951BECTP-GH7 is a single-channel eSATA ReDriver designed for high-speed signal integrity applications. Operating at data rates up to 3Gbps, this buffer features robust signal conditioning capabilities, including input equalization and output pre-emphasis, to overcome signal degradation in complex routing environments. The device is housed in a compact 20-TQFN (4x4) package, suitable for surface mount assembly. With a supply voltage range of 3V to 3.6V and a typical supply current of 77mA, the MAX4951BECTP-GH7 is engineered for efficient operation. Its typical delay time is 150ps. This component is commonly utilized in data storage systems and consumer electronics requiring reliable eSATA connectivity.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 20-WFQFN Exposed Pad |
| Delay Time | 150ps |
| Number of Channels | 1 |
| Mounting Type | Surface Mount |
| Output | - |
| Type | Buffer, ReDriver |
| Input | - |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3V ~ 3.6V |
| Applications | eSATA |
| Current - Supply | 77mA |
| Data Rate (Max) | 3Gbps |
| Supplier Device Package | 20-TQFN (4x4) |
| Signal Conditioning | Input Equalization, Output Pre-Emphasis |
