MAX14986ETI+
IC REDRIVER SAS/SATA 1CH 28TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Signal Buffers, Repeaters, Splitters
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX14986ETI- is a 1-channel SAS/SATA ReDriver designed for robust signal integrity in demanding applications. This buffer component offers precise signal conditioning through input equalization and output pre-emphasis, mitigating signal degradation over high-speed interfaces. Operating from a 3V to 3.6V supply, it consumes a typical current of 175mA. The device features a low propagation delay of 300ps, crucial for maintaining timing accuracy in data transmission. Packaged in a 28-TQFN (3.5x5.5) with an exposed pad, the MAX14986ETI- is suitable for surface mount assembly. Its primary applications include systems utilizing SAS and SATA protocols, commonly found in enterprise storage, networking, and data center infrastructure. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 44 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-WFQFN Exposed Pad |
| Delay Time | 300ps |
| Number of Channels | 1 |
| Mounting Type | Surface Mount |
| Output | - |
| Type | Buffer, ReDriver |
| Input | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 3.6V |
| Applications | SAS, SATA |
| Current - Supply | 175mA |
| Data Rate (Max) | - |
| Supplier Device Package | 28-TQFN (3.5x5.5) |
| Signal Conditioning | Input Equalization, Output Pre-Emphasis |
