MAXREFDES100#
EVKIT HEALTH SENSOR PLATFORMManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Sensor Evaluation Boards
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAXREFDES100- is an evaluation kit designed for the development of advanced health and fitness monitoring systems. This platform integrates the MAX30003 analog front-end for ECG and bio-impedance measurements, the MAX30101 for pulse oximetry and heart rate sensing, and the MAX30205 digital temperature sensor. The system is powered by the MAX32620 32-bit microcontroller, offering robust processing capabilities for real-time data acquisition and analysis. Connectivity is provided via USB. This comprehensive evaluation board is utilized in the medical, health, and fitness industries for rapid prototyping and validation of wearable and portable health devices. It is supplied with the necessary boards and cables for immediate use.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Sensitivity | - |
| Interface | USB |
| Voltage - Supply | - |
| Sensor Type | Medical, Health and Fitness |
| Utilized IC / Part | MAX30003, MAX30101, MAX30205, MAX32620 |
| Supplied Contents | Board(s), Cable(s) |
| Embedded | Yes, MCU, 32-Bit |
| Sensing Range | - |
