MAX2034CTM+T
IC RF AMP SONAR 70MHZ 48TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: RF Amplifiers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX2034CTM-T is a high-performance RF amplifier IC designed for SONAR applications operating at a center frequency of 70MHz. This device offers a typical gain of 19dB with a noise figure of 2.2dB, ensuring excellent signal amplification and low signal-to-noise ratio. The amplifier is optimized for a supply voltage range of 4.75V to 5.25V, drawing a supply current between 46.5mA and 54.5mA. Its output third-order intercept point (IP3) is 3dBm. The MAX2034CTM-T is housed in a compact 48-TQFN (7x7) package with an exposed pad, facilitating efficient heat dissipation and robust surface mount assembly. This component finds application in sonar systems and other demanding RF signal processing tasks. The device is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 70MHz |
| RF Type | SONAR |
| Voltage - Supply | 4.75V ~ 5.25V |
| Gain | 19dB |
| Current - Supply | 46.5mA ~ 54.5mA |
| Noise Figure | 2.2dB |
| P1dB | 3dBm |
| Test Frequency | - |
| Supplier Device Package | 48-TQFN (7x7) |
