DS1553W-150
IC RTC CLK/CALENDAR PAR 28EDIPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Real Time Clocks
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS1553W-150 is an 8KB Parallel Real Time Clock (RTC) module featuring clock/calendar functionality. This Clock/Calendar IC operates within a voltage supply range of 2.97V to 3.63V, with a battery voltage of 3V and a timekeeping current consumption of 2mA at 3.3V. Key features include alarm, leap year support, NVSRAM, a watchdog timer, and Y2K compliance. The device offers parallel interface for data access and supports both YY-MM-DD-dd date format and HH:MM:SS (24 hr) time format. The DS1553W-150 comes in a 28-EDIP package, with a 28-DIP Module (0.600", 15.24mm) package/case, and is designed for through-hole mounting. This component is commonly utilized in industrial automation, medical devices, and embedded systems requiring precise timekeeping.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Alarm, Leap Year, NVSRAM, Watchdog Timer, Y2K |
| Packaging | Tube |
| Package / Case | 28-DIP Module (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Memory Size | 8KB |
| Interface | Parallel |
| Type | Clock/Calendar |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 2.97V ~ 3.63V |
| Time Format | HH:MM:SS (24 hr) |
| Date Format | YY-MM-DD-dd |
| Supplier Device Package | 28-EDIP |
| Voltage - Supply, Battery | 3V |
| Current - Timekeeping (Max) | 2mA @ 3.3V |
| Programmable | Not Verified |
