DS1511W+
IC RTC CLK/CALENDAR PAR 28EDIPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Real Time Clocks
Quality Control: Learn More
Real Time Clock (RTC) IC Clock/Calendar 256B Parallel 28-DIP Module (0.600"", 15.24mm)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 24 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Alarm, Leap Year, NVSRAM, Square Wave Output, Watchdog Timer, Y2K |
| Packaging | Tube |
| Package / Case | 28-DIP Module (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Memory Size | 256B |
| Interface | Parallel |
| Type | Clock/Calendar |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3V ~ 3.6V |
| Time Format | HH:MM:SS (24 hr) |
| Date Format | YY-MM-DD-dd |
| Supplier Device Package | 28-EDIP |
| Voltage - Supply, Battery | 2.5V ~ 3.7V |
| Current - Timekeeping (Max) | 4mA @ 3V ~ 3.6V |
| Programmable | Not Verified |
