MAX8535AEUA+T
IC OR CTRLR N+1 8UMAXManufacturer: Analog Devices Inc./Maxim Integrated
Categories: OR Controllers, Ideal Diodes
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX8535AEUA-T is an N+1 ORing controller designed for high-reliability power management. This component features an N-channel FET topology, enabling efficient current steering in redundant power supply configurations. The MAX8535AEUA-T operates within an 8V to 14V supply voltage range and consumes a low 2mA quiescent current. Its 8-uMAX/uSOP package is suitable for surface mount applications, and it offers a typical turn-off delay of 200 ns. This device is utilized in demanding sectors such as Telecom Infrastructure, where maintaining uninterrupted power is critical. The component is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Type | N+1 ORing Controller |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 8V ~ 14V |
| Applications | Redundant Power Supplies, Telecom Infrastructure |
| Internal Switch(s) | No |
| FET Type | N-Channel |
| Delay Time - OFF | 200 ns |
| Current - Output (Max) | - |
| Ratio - Input:Output | N:1 |
| Supplier Device Package | 8-uMAX/uSOP |
| Current - Supply | 2 mA |
Request a Quote
