MAX22205ATU+
DUAL H-BRIDGE FOR STEPPER AND BRManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Motor Drivers, Controllers
Quality Control: Learn More
Bipolar Motor Driver NMOS On/Off, PWM 38-TQFN (5x7)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 21 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 38-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 7.6A |
| Interface | On/Off, PWM |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 4.5V ~ 65V |
| Applications | DC Motors, General Purpose, Stepper Motors |
| Technology | NMOS |
| Voltage - Load | 4.5V ~ 65V |
| Supplier Device Package | 38-TQFN (5x7) |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | 1, 1/2 |
