TMCM-6212-CANOPEN
STEPPER DRIVER 1.1A 11V-35VManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Motor Driver Boards, Modules
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated TMCM-6212-CANOPEN is a 6-axis bipolar stepper motor driver module. This board is designed for demanding applications requiring precise motor control and robust communication interfaces. Each axis delivers a continuous output current of 1.1A with a load voltage range of 11V to 35V, and operates with a 24VDC supply. The TMCM series module features integrated CANopen and RS-485 interfaces, alongside USB for flexible system integration and configuration. Its chassis mount design facilitates integration into industrial automation, robotics, and medical equipment. The module operates within an ambient temperature range of -30°C to 40°C.
Additional Information
Series: TMCMRoHS Status: ROHS3 CompliantManufacturer Lead Time: 69 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| For Use With/Related Products | - |
| Mounting Type | Chassis Mount |
| Current - Output | 1.1A |
| Interface | CAN, RS-485, USB |
| Type | Board |
| Operating Temperature | -30°C ~ 40°C |
| Voltage - Supply | 24VDC |
| Voltage - Load | 11V ~ 35V |
| Number of Motors | 6 |
| Motor Type | Stepper |
| Control / Drive Type | Stepper, Bipolar |
