TMCM-1110-STEPROCKER
STEPPER DRIVER 1A 2.8A 10-30VManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Motor Driver Boards, Modules
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated TMCM-1110-STEPROCKER is a bipolar stepper motor control board designed for high-performance motion control applications. This module supports a supply voltage range of 12 to 24VDC and delivers an output current of 1A to a maximum of 2.8A, suitable for driving stepper motors. The TMCM series board offers flexible control interfaces including RS-485, Step/Direction, and USB for seamless integration into various automation systems. It is engineered for chassis mounting and operates reliably within an ambient temperature range of -25°C to 80°C. This component is commonly found in industrial automation, robotics, and general motion control systems requiring precise stepper motor operation.
Additional Information
Series: TMCMRoHS Status: ROHS3 CompliantManufacturer Lead Time: 71 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| For Use With/Related Products | - |
| Mounting Type | Chassis Mount |
| Current - Output | 1A, 2.8A |
| Interface | RS-485, Step / Direction, USB |
| Type | Board |
| Operating Temperature | -25°C ~ 80°C |
| Voltage - Supply | 12 ~ 24VDC |
| Voltage - Load | 10 ~ 30V |
| Number of Motors | 1 |
| Motor Type | Stepper |
| Control / Drive Type | Stepper, Bipolar |
