73S1113F-CGT/F

IC MCU 8BIT 64KB FLASH 64LQFP

Manufacturer: Analog Devices Inc./Maxim Integrated

Categories: Microcontrollers

Quality Control: Learn More

Analog Devices Inc./Maxim Integrated 73S1113F-CGT-F is an 8-bit microcontroller belonging to the 73S11xx series. This device features an 80C52 core with a maximum operating speed of 24MHz. It offers 64KB of FLASH program memory and 5KB of RAM. Connectivity options include SmartCard, UART/USART, and USB interfaces. The microcontroller is equipped with 15 I/O pins and peripherals such as an LCD controller. This surface-mount component is housed in a 64-LQFP (10x10) package. The operating voltage range is 2.7V to 3.6V, with an operating temperature range of 0°C to 85°C. This component is utilized in applications such as smart card readers and embedded systems requiring robust 8-bit processing capabilities.

Additional Information

Series: 73S11xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tray
Technical Details:
PackagingTray
Package / Case64-LQFP
Mounting TypeSurface Mount
Speed24MHz
Program Memory Size64KB (64K x 8)
RAM Size5K x 8
Operating Temperature0°C ~ 85°C
Oscillator TypeInternal
Program Memory TypeFLASH
EEPROM Size-
Core Processor80C52
Data Converters-
Core Size8-Bit
Voltage - Supply (Vcc/Vdd)2.7V ~ 3.6V
ConnectivitySmartCard, UART/USART, USB
PeripheralsLCD
Supplier Device Package64-LQFP (10x10)
Number of I/O15
ProgrammableNot Verified
