DS1609-50+
IC SRAM 2KBIT PARALLEL 24DIPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Memory
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS1609-50- is a 2Kbit asynchronous dual-port SRAM with a 50 ns access time. This memory component features a parallel interface and a 256 x 8 memory organization. Designed for through-hole mounting, it is supplied in a 24-PDIP package. The device operates across a voltage range of 4.5V to 5.5V and supports a write cycle time of 50 ns. The DS1609-50- is suitable for applications in industrial automation, telecommunications, and consumer electronics where reliable, fast memory access is critical. Its operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-DIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Memory Size | 2Kbit |
| Memory Type | Volatile |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 4.5V ~ 5.5V |
| Technology | SRAM - Dual Port, Asynchronous |
| Memory Format | SRAM |
| Supplier Device Package | 24-PDIP |
| Write Cycle Time - Word, Page | 50ns |
| Memory Interface | Parallel |
| Access Time | 50 ns |
| Memory Organization | 256 x 8 |
| Programmable | Not Verified |
