DS1265AB-100
IC NVSRAM 8MBIT PARALLEL 36EDIPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Memory
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS1265AB-100 is an 8Mbit Non-Volatile SRAM (NVSRAM) memory device with a parallel interface. This component features an access time of 100 ns and a write cycle time of 100 ns. The memory is organized as 1M x 8. It operates within a supply voltage range of 4.75V to 5.25V and has an operating temperature range of 0°C to 70°C. The DS1265AB-100 is housed in a 36-EDIP package and is designed for through-hole mounting. This NVSRAM is utilized in applications requiring data retention without constant power, commonly found in industrial control systems and data logging equipment.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 36-DIP Module (0.610"", 15.49mm) |
| Mounting Type | Through Hole |
| Memory Size | 8Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Technology | NVSRAM (Non-Volatile SRAM) |
| Memory Format | NVSRAM |
| Supplier Device Package | 36-EDIP |
| Write Cycle Time - Word, Page | 100ns |
| Memory Interface | Parallel |
| Access Time | 100 ns |
| Memory Organization | 1M x 8 |
| Programmable | Not Verified |
