MAX8559ETA11+
IC REG LINEAR 1.85V/1.85V 8TDFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX8559ETA11- is a dual-output linear voltage regulator featuring positive fixed outputs of 1.85V, each capable of supplying up to 300mA. This device offers excellent power supply rejection ratio (PSRR) performance, ranging from 70dB down to 54dB across the 10kHz to 100kHz frequency spectrum. The MAX8559ETA11- incorporates critical protection features including over-current, over-temperature, and short-circuit protection. With a quiescent current of 290 µA and an input voltage range up to 6.5V, it is suitable for applications requiring efficient power management. The component is supplied in an 8-TDFN-EP (3x3) package for surface mounting. This regulator finds application in various industries including consumer electronics and telecommunications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-WDFN Exposed Pad |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 300mA, 300mA |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 290 µA |
| Voltage - Input (Max) | 6.5V |
| Number of Regulators | 2 |
| Supplier Device Package | 8-TDFN-EP (3x3) |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 1.85V, 1.85V |
| Control Features | Enable |
| PSRR | 70dB ~ 54dB (10kHz ~ 100kHz) |
| Voltage Dropout (Max) | -, - |
| Protection Features | Over Current, Over Temperature, Short Circuit |
